Description
Parameters
| Order model | Wattage | Dimension | Lumens | Color temperature | IP Grade | CRI | Power Factor | Beam angle | Input voltage | DATASHEET |
| LLS-CD-12WH | 12W±5% | Ø275XH110mm | 1000-1200lm | 3000K;4000K;6500K | IP65 | >80 | >0.5 or >0.9 | 120° | 100-265VAC 50/60Hz | Download |
| LLS-CD-15WH | 15W±5% | Ø275XH110mm | 1400-1600lm | 3000K;4000K;6500K | IP65 | >080 | >0.5 or >0.9 | 120° | 100-265VAC 50/60Hz | Download |
| LLS-CD-18WH | 18W±5% | Ø275XH130mm | 1600-1800lm | 3000K;4000K;6500K | IP65 | >80 | >0.5 or >0.9 | 120° | 100-265VAC 50/60Hz | Download |
| LLS-CD-24WH | 24W±5% | Ø325XH130mm | 2000-2400mm | 3000K;4000K;6500K | IP65 | >80 | >0.5 or >0.9 | 120° | 100-265VAC 50/60Hz | Download |
Specification
Body & Finished
- Bottom: Flame-retardant ABS chassis. White finished fire-rated level
- Outer trim: High-strength plastic, curved design, white powder coated
- Cover: Acrylic PMMA cover, light transmittance up to 90%, uniform light effect, no dark spots
- Surface parts: Plastic part, easy to fix onto ceiling or wall
- Cables & wiring: cable with DC connector as standard, fast connection
Control gear / Led driver
- LED Driver type: Isolated driver
- Brand: DONE/SUNCOM/GX/DNF
- Input voltage: 110/220-240VAC 50/60Hz
- Power factor: >0.5 as standard, >0.9 optional
- THD:<20%
- IP rated: IP65 waterproof
- Warranty: 2/3/5years
- Surge protection :1 KV
Optical
- Led chips: Bridgelux SMD
- Lumens:110-140lm/W
- Color temperature: 3000K warm white, 4000k daylight, 6500k cold white.
- SDCM: <5%
- LM80
Option
- Dimming ( Triac dimmable/ 0-10V dimming /DALI dimming optional)
- Radar Sensor
- Emergency kits( 2W-3W with 1hrs 2hrs
Application
- Balcony and Porch
- Bathroom
- Washrooms
- Basements
FAQ
Q: What lights are suitable for showers?
A: Waterproof lights with IP65 or higher, are suitable for showers. Surfaced mounted or recessed IP65 led downlights are good for functional lighting. Waterproof LED strip lights and sconces wall lights can be installed to provide ambient lighting. it is essential to prioritize safety and ensure they can withstand the presence of water and steam in wet areas like bathrooms.
Q: Can IP65 lights be used outside?
A: Yes, IP65 lights can be used outside. In fact, IP65 is a common rating for outdoor lights because it provides a high level of protection against dust and water ingress, so it can withstand rain and splashes and is suitable for outdoor environments such as Porch or Entryway Lighting, Landscape Lighting, Deck and Patio Lighting, Security Lighting, Pool Area Lighting
