Description
Parameters
| Order Model | Wattages | Type | Dimension | Cut out | Lumens | UGR | CRI | Color temperature | Input voltage | Datasheets |
| LLS-DL-7WG-6 | 5W/7W | Trim or trimless | Φ62*H68mm | Φ50-55mm | 500-700lm | <15 | >90 | 3000K, 4000K, 6500K | 110/220-240VAC | Download |
| LLS-DL-10WG-6 | 10W | Trim or trimless | Φ83*80mm | Φ70-75mm | 630-770lm | <15 | >90 | 3000K, 4000K, 6500K | 110/220-240VAC | Download |
| LLS-DL-15WG-6 | 15W±5% | Trim or trimless | Φ105*100mm | Φ95mm | 1400-1600lm | <15 | >90 | 3000K, 4000K, 6500K | 110/220-240VAC | Download |
| LLS-DL-20WG-6 | 20W±5% | Trim or trimless | Φ105*110mm | Φ95mm | 1800-2100lm | <15 | >90 | 3000K, 4000K, 6500K | 110/220-240VAC | Download |
| LLS-DL-25WG-6 | 24W±5% | Trim or trimless | Φ134*110mm | Φ115mm | 2300-2600lm | <15 | >90 | 3000K, 4000K, 6500K | 110/220-240VAC | Download |
Specification
Materials & Finished
- Trim: aluminum, matt white as standard
- Trimless: aluminum
- Heat sink: Die-cast aluminum, black powder coated.
- Reflector: PMMA materials, white/black reflectors as standard, Gun black/ bright black reflectors optional.
- Springs/Clips: Steel, high strength to fix onto the ceiling.
Control Gear / Led driver
- Driver brand: Eagleries as standard; LiFud/Euchips/Osram/Philips/Letch/Sunricher optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Free flicker: Yes
- Power factor:>0.5 or >0.9
- Dimmable: No.
- THD:<15%
- Efficiency:>88%
- IP Rating: IP22
- Certificates: TUV CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram available
- Color rendering index:>90
- Lumens:100lm-120lm/W output.
- SDCM:<3
- Lifetime:>50000Hrs
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
Option
- Emergency backup kits
- 0-10V/ Phase triac dimming/DALI dimming
- 3CCT color changing
- Zigbee smart downligh
