Series Leaf Modern LED Street Light Fixtures With Free-tool Design

Leaf series modern LED street light fixtures are a new series launched by LUMIOS in 2025. It offers many benefits, such as tool-free opening, a sleek casing, and a modern design ( View modern street lamp project case ). LUMIOS gave this series the name “Leaf”, aiming to allow these street lights to be seamlessly integrated into urban infrastructure. Just like leaves covering the sides or middle of roads, providing lighting to the city.

Product Features

Power range 20W-160W
Free-tool maintenance
High performance with Lumileds chips
Luminaire efficiency up to 199 lm/W
Build-in 10KV surge protection device ( Surge Protection Devices (SPD) for LED lighting )
Two light distributions
Customized dimming profile as per request
ENEC certified for both Class I and II
Available on request: NEMA socket (3/5/7pins), ZHAGA socket, Short cap, Daylight sensor, Motion sensor, NTC, OLC, Solar Compatible, DALI Dimming

Category: LED street light

Description
Reviews (0)

Description

Parameters

Product Code	Series Leaf
Power	20W, 30W, 40W, 50W, 60W, 70W, 80W, 90W, 100W, 110W, 120W, 130W, 140W, 150W, 160W
Efficacy	155-199lm/W
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request) with IEC61643-11
IP Rating	IP66
IK Rating	IK09
CCT	2200K, 3000K, 4000K, 5000K, 5700K, 6500K
CRI	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle	Type II, Medium
Mounting Option	Side entry, or vertical pole mounted with adapters
Warranty	5 Years
Certification	CE, RoHS, ENEC, CB, Zhaga-D4i, LM79, LM80, TM-21, IP66, IK09/IK10, IEC62471/62778, IEC60068-2-6, IEC61643-11, ISO9227, CISPR15:2018
Control	Daylightsensor, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control
