Series Kmini2 Eco But Quality Ensured Led Light Street

Series Kmini2 Led Light Street has almost full TUV approved certificates and test reports. Such as CE EMC, LVD, CB, ENEC, IP66, IK08/IK10, Salt Spray Test, and 3G vibration test. From 40W to 150W, the regular wattages can well fulfill the clients’ needs and requirements of the tender. Standard 10KV Surge Protection Device. It is easy for maintenance because its back cover can be opened without any tool. Most importantly, the pricing of Series Kmini2 is competitive and the performance is excellent.

Product Features

Nominal power: 60-150W
Small and compact design
IP66 and IK08/IK10
Good-quality and energy-efficient
10 /20KV surge protection
130lm/w and 160lm/w for optional
Smooth body, self-cleaning
ENEC, CE, CB certified.
Smart Control: 1-10V/ DALI dimming, NEMA, Zhaga, Photocell, Motion sensor, Zigbee /Lora socket for smart control system or future updating

Category: LED street light

Description
Reviews (0)

Description

Parameters

Product Code	Series Kmini2
Power	60W, 70W, 80W,90W, 100W, 110W, 120W, 130W, 150W
Efficacy	130-160lm/W
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request)
Ingress Protection(IP)	IP66
IK Rating	IK08 / IK10
CCT	3000K, 4000K, 5000K, 5700K
CRI(Ra)	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle(deg)	Type II, Medium;
Mounting Option	Side entry or Vertical pole mounted ( with extra adapter)
Warranty	5 Years
Certification	ENEC, CE, CB, Zhaga-D4i, ROHS, LM79, IP66, IK08/IK10, LM80, LM82, LM84, TM-21, ISTMT, IEC62471/62778, IEC60068-2-6, IEC61643-11, ISO9227, CISPR15:2018
Control	Photocell, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control
