Series Helios 190LM/W UFO High Bay Light

Helios is an economical UFO High Bay Light, the radiator is made of high-quality ADC12 aluminum alloy die-casting, has a very good heat dissipation effect, use high luminous efficiency LED chips, and the whole fixture efficiency reaches 190lm/W, as an industrial lighting lamp, it can be combined with motion sensor and daylight sensor to achieve the maximum energy saving. Can also achieve a dimming function, Helios series are dimmable led ufo lights.

Product Features

  • Watts : 100W,150W,200W
  • Light Efficiency up to 190lm/w
  • IK08, IP65 waterproof
  • 70% energy saving, short ROI period
  • Wide choice of optics for different lighting arrangements
  • Hook Loop or Bracket mounting
  • CE, ROHS certified
  • Plug-in sensor
  • Smart Control : 1-10V dimming, DALI control, Photocell, Motion/PIR sensor.
Category:

Description


Parameters

Product Code Power Efficacy Input Voltage Power Factor Surge Protection Ingress Protection(IP) IK Rating CCT CRI(Ra) Operating Temperature Beam Angle(deg) Mounting Option Warranty Certification Control
Series Helios 100W,150W, 200W 140-190lm/W 100-240/277 VAC, 50 / 60 Hz >0.95 4KV line-line, 6KV line-earth IP65 IK10 3000K, 4000K, 5000K, 5700K Ra>70 (Default) / Ra>80 -40°C to + 50°C 60°, 90° or 110° Hook Loop, Various Brackets 5 Years CE, ROHS, LM80, TM-21 DALI Dimmable, Motion/PIR Sensor, Non-Dimmable, 1-10V Dimmable

Downloads



  • Specification_Helios_BayLight
  • Installation Manual_HighBay Light_Helios
