Series HB12 UFO LED High Bay With Tunable White LEDs

Series HB12 UFO LED High Bay With Tunable White LEDs

Series HB12 UFO LED high bay has a classic UFO design with a power range up to 500W and a luminous efficiency of up to 190lm/w ( Benefits of high luminous efficacy ). Its durable black powder coated housing, clear lens and optional multiple beam angles ensure uniform lighting in large spaces. The light fixture is adjustable in both power and color temperature, and is equipped with a high-quality power supply with a 3-position dial switch, providing a dynamic lighting solution. This advanced feature solves the problem of not being able to purchase in stock when users are unsure of the color temperature or power of the high bay lights.

Product Features

  • Power can reach up to 500W
  • High luminous efficacy: Up to 190lm/W
  • Full die-casting aluminum housing
  • CCT & Power Selectable
  • Wide options for symmetry optics 40°, 60°, 90°, and 110°
  • Long lifespan with L70 >50,000 hours
  • Optional accessories: Alu reflector, U bracket, Emergency battery, Steel rope
  • ENEC, CE, CB certified
  • Smart Control: 1-10V/ DALI dimming , Motion sensor, Zhaga socket
Category:

Description

Parameters

Product Code LLS-HB12-60 LLS-HB12-100 LLS-HB12-150 LLS-HB12-200 LLS-HB12-240 LLS-HB12-300 LLS-HB12-400 LLS-HB12-500
Power 60W 100W 150W 200W 240W 300W 400W 500W
Input Voltage AC100-277V, 50/60Hz
Lumen EFF. 150lm/W,170lm/W,190lm/W
Lumen Flux(+5%) 9,000LM 15,000LM 22,500LM 30,000LM 36,000LM 45,000LM 60,000LM 75,000LM
10,200LM 17,000LM 25,500LM 34,000LM 40,800LM 51,000LM 68,000LM 85,000LM
11,400LM 19,000LM 28,500LM 38,000LM 45,600LM 57,000LM 76,000LM 95,000LM
QTY Of LEDS(PCS) 130/172 208/300 300/450 420/680 420/680 616/935 1100/1530 1100/1530
LED Brand LUMILEDS 2835 /SAN’AN 2835
Driver Brand SOSEN Or PHILIPS MOSO
CCT 3000K,4000K,5000K,5700K,6500K and 3CCT ADJ
CRI (Ra) >70/80
PF 0.95
Beam Angle(deg) 60°/90°/110° 40°/60°/90°
Ingress Protection(IP) IP65
IK Rating IK08
Warranty 5-year@SOSEN & MOSO, 7-year@PHILIPS
Physical dimension(mm) 233*145 260*145 287*147 305*149 305*149 342*168 447*178 447*178
