Series Falcon Smart Street Light with NEMA or ZHAGA , 1-10v/DALI2 D4i

Series Falcon Smart Street Light can be equiped with 0-10V, 1-10V, DALI, DALI2 D4i LED driver, perfect work with 3PIN, 5PIN or 7PIN NEMA socket and ZHAGA socket to fit the ZIGBEE, LORA, Motion/PIR or Casambi nodes to achieve remote smart control by software or App in future.
A Cut-off Knife switch can be added inside the power box. When the maintenance personnel opens the rear cover of the street lamp, the lamp can automatically cut off the power, which greatly increases the safety of the lamp.

Product Features

Power range 20W-200W
Free-tool maintenance
High performance with Lumileds chips
Luminaire efficiency up to 188 lm / W.
Build-in 10KV surge protection device
Power-off protection is optional
over 12 optics lens for options
Side entry or Vertical mounted
ENEC certified for both Class I and II

Category: LED street light

Description
Reviews (0)

Description

Parameters

Product Code	Series Falcon
Power	30W, 50W, 60W, 80W, 100W, 120W, 150W, 180W, 200W
Efficacy	145-188lm/W
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request) with IEC61643-11
Ingress Protection(IP)	IP66
IK Rating	IK09 / IK10
CCT	3000K, 4000K, 5000K, 5700K
CRI(Ra)	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle(deg)	Type II, Medium; Type III, Medium;
Mounting Option	Side entry or Vertical pole mounted
Warranty	5 Years
Certification	CE, RoHS, ENEC, ENEC+, CB, Zhaga-D4i, LM79, LM80, TM-21, IP66, IK09/IK10, IEC624711/62778, IEC60068-2-6, IEC61643-11, ISO9227, CISPR15:2018
Control	Photocell, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control
