Description
Parameters
Order Model |
Wattage |
Inch |
Dimension |
Cut out |
Lumens |
Color temperature |
Beam angle |
IP Rate |
led type |
Input voltage |
Specification |
| LLS-DL-15WN | 15W ± 5% | 4in | Ø145*H60mm | Ø120-125mm | 1350-1600lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
| LLS-DL-20WN | 20W ± 5% | 5in | Ø160*H60mm | Ø140-145mm | 1900-2200lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
| LLS-DL-30WN | 30W ± 5% | 6in | Ø190*H60mm | Ø165-175mm | 2800-3200lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
| LLS-DL-40WN8 | 40W ± 5% | 8in | Ø230*H75mm | Ø195-210mm | 3750-4200lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
| LLS-DL-40WN9 | 40W ± 5% | 9in | Ø250*H75mm | Ø210-230mm | 3750-4200lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
| LLS-DL-40WN10 | 40W ± 5% | 10in | Ø300*H110mm | Ø240-280mm | 3750-4200lm | Warm white/daylight | 90/120° | IP20 | COB/SMD | 110/220-240VAC | Download |
Description
Material & Finished
- Outer trim: Aluminum, white finished
- Heat sink: Die-cast aluminum, black finished
- Reflector: Only for COB type, silver finished, plastic.
- Cover: Glass cover for COB type, PMMA Cover for SMD type.
- Spring clips: Steel.
- Cable: rubber cable.
Control gear / Optical
- Control gear brand: LiFud/Eagleries as standard. Philips/Osram optional
- Working voltage:110/220-240VAC 50/60Hz
- Power Factor:>0.5 as standard or >0.9 optional
- THD:<10%
- Color rendering index:>90
- Lumens:90lm-110lm/W output.
- SDCM:<3
- Efficiency:>85%
- IP Rating: IP20 Indoor use
- Beam angle: 60° Medium distribution for COB; 120° for SMD.
- Lifetime:>50000Hrs
- Working temperature:-25℃/+55℃
- Compliance: CE RoHS Certified
- Warranty:3/5 Years.
Options
- Zigbee/ WIFI Mesh / CCT Tunable/ remote controller
- PWM/0-10V/DALI Dimmable
- Emergency battery pack
Application
Commercial lighting for hotels, offices, supermarkets, and shopping malls.
Industrial lighting for garbage, parking lots, subway stations, bus stations and warehouses
