Description
Parameters
Product Code |
Wattage |
Dimension |
LED QTY |
Lumens |
CRI(Ra) |
PF |
Color Temperature |
Installation |
Input voltage |
Datasheet |
| LLS-LS7575-600 | 18W | L600*W75*H75mm | 96pcs SMD2835 | 1800-2000lm | >80 | >0.92 | 3000K4000K6500K | Pendant/ Surface mounted | 100-240VAC 50/60Hz | Download |
| LLS-LS7575-1200 | 36W | L1200*W75*H75mm | 192pcs SMD2835 | 3800-4100lm | >80 | >0.92 | 3000K4000K6500K | Pendant/ Surface mounted | 100-240VAC 50/60Hz | Download |
| LLS-LS7575-1500 | 48W | L1500*W75*H75mm | 240pcs SMD2835 | 4800-5000lm | >80 | >0.92 | 3000K4000K6500K | Pendant/ Surface mounted | 100-240VAC 50/60Hz | Download |
| LLS-LS7575-2400 | 80W | L2400*W75*H75mm | 382pcs SMD2835 | 8000-8600lm | >80 | >0.92 | 3000K4000K6500K | Pendant/ Surface mounted | 100-240VAC 50/60Hz | Download |
Specification
Materials & Finished
- Unique product design, simple and stylish appearance, easy to install and maintain;
- The light efficiency of the linear suspension light is above 95Lm/W, and the color rendering index is greater than Ra80;
- Lamp body material: 6063 high-quality aluminum alloy + high-quality PC lampshade;
- With 0-10V, thyristor, DALI dimming function, and sensing and emergency functions;
- Suspension ceiling lights can be installed and applied in combination of T type, L type, X type, and straight-line;
- The length 2ft, 3ft, 3.28ft, 4ft, 5ft, 6ft, 8ft, 10ft available
Photometric Data
- Power Factor:>0.92
- Color rendering index:>80
- Lumens:100lm/W
- SDCM:<5
- Efficiency:>89%
- Dimmable: No
- IP Rating: IP22 Indoor use
- Beam angle: 120°
- Color temperature: 3000K Warm white /4000K daylight/6500K cool white.
- Working temperature:-25℃/+60℃
