Description
Parameters
Model |
Length |
Power(Pcs) |
Voltage |
Color Temperature |
Beam Angles |
Control |
Chips Brand |
| KMBD-ZY2.2-PZ-18A | 135*200*185mm | 27W(18pcs) | AC220V
DC24V |
2700K-6500K | 8° / 10° / 13° / 15° / 20° / 25° / 40° / 45° | ON/OFF | CREE
OSRAMS EPISTAR LUMILED SANAN |
| KMBD-ZY2.2-PZ-18A/B | 27W(18pcs) | 2200K-6500K
1800K-3000K+4000K-6500K |
DMX512 | ||||
| KMBD-ZY2.2-PZ-18C | 27W(18pcs) | RGB | 15° / 25° / 45° / 60° | ||||
| KMBD-ZY2.2-18D | 27W(18pcs) | RGBW |
Housing material:
- High-strength die-cast aluminum
- Ultra-clear tempered glass
- Waterproof silicone gasket
Surface Finish :
Electrostatically applied polyester powder coat
Installation:
- Non-adjustable brackets
- Luminaires are not allowed to be installed in low-lying water
Cable:
- ON/OFF: 500mm two-core 0.75mm²sheathed cable (Power cable)
- ON/OFF AC220V:500 three-core 0.75mm²anti-siphon cable (Power cable)
- DMX512: 500mm six-core 2*0.75+4*0.3mm²sheathed cable (Power and signal in a cable) 500mm five-core 2*1+3*0.3mm²(Power and signal in a cable)
