Description
Parameters
Order Model |
Wattage |
Dimension |
Cut out |
Lumens |
Color temperature |
UGR |
IP rating |
Input voltage |
Ra |
Datasheet |
| LLS-DL-12WB-02 | 12W±5% | Ø83*65mm | Ø75mm | 1200-1400lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
| LLS-DL-15WB-02 | 15W±5% | Ø83*65mm | Ø75mm | 1400-1600lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
| LLS-DL-20WB-02 | 20W±5% | Ø103*H70mm | Ø95mm | 2000-2400lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
| LLS-DL-25WB-02 | 25W-30W±5% | Ø132*75mm | Ø125mm | 2500-3000lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
| LLS-DL-30WB-02 | 30W-35W±5% | Ø160*80mm | Ø150mm | 3050-3600lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
| LLS-DL-40WB-02 | 40W±5% | Ø180*85mm | Ø170mm | 4050-4800lm | 3000K/4000K/6500K | <17 | IP65 | 110/220-240VAC | >92 | Download |
Specifications
Materials & Finished
- Housing: Aluminum body, white finished as standard; black optional.
- Reflector: white as standard; black/silver/ Gold optional.
- Cover: PMMA cover, frosted
- Spring Clips: Iron body, strongest strength. Easy to do the recessed ceiling installation
- Gland: IP65 Stainess steel waterproof gland
Control Gear / Led driver
- Led driver brand: LiFud/ Eagleries as standard; Osram/Philips as optional.
- Input voltage: 110/220-240VAC 50/60Hz.
- Power Factor:>0.5 as standard, 0.9 optional
- Efficiency:>85%
- IP Grade: IP22
- THD:<15%
- Surge protection: 1-2KV
- Working temp: -25℃/+55℃
- Certificate: CE RoHS ENEC CB
- Warranty: 3/5 years.
Optical
- Light source brand: Bridgelux/Epistar/Osram COB
- Chips lumens:120-150lm/W
- CRI: >92
- UGR:<15
- Color temperature: 2700-3000K, 4000-4500K, 5700-6500K
- SDCM:<3
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80)
Options
- Emergency battery packs. ( Emergency 1-3hours with 2-5Watt)
- Phase/0-10V/DALI Dimmable
- CCT selectable downlight
- Zigbee smart controlled
Applications and Project Case
- Residential places like Living room, kitchen room, Bedroom.
- Commercial lighting: Hotels, Schools, Supermarkets, clothes stores, and Offices lighting
Reviews
There are no reviews yet.
