Description
Parameters
| Order Model | Wattages | Dimension | Cut out | Lumens | Beam angle | Color temperature | CRI | IP Rating | Input voltage | Datasheet |
| LLS-DL-15WB-09 | 15W±5% | Φ115*H60mm | Φ105mm | 1350-1500lm | 15/24/36/60° | 3000K,4000K,6000K | >92 | IP54 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-25WB-09 | 25W±5% | Φ136*H70mm | Φ125mm | 2250-2600lm | 15/24/36/60° | 3000K,4000K,6000K | >92 | IP54 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-35WB-09 | 35W±5% | Φ162*H80mm | Φ150mm | 3300-3600lm | 15/24/36/60° | 3000K,4000K,6000K | >92 | IP54 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-40WB-09 | 40W±5% | Φ195*H95mm | Φ175mm | 3800-4400lm | 15/24/36/60° | 3000K,4000K,6000K | >92 | IP54 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-50WB-09 | 50W±5% | Φ220*H105mm | Φ200mm | 4800-5500lm | 15/24/36/60° | 3000K,4000K,6000K | >92 | IP54 | 110/220-240VAC 50/60Hz | Download |
Materials & Finished
- Housing: aluminum, matt white as standard, matt black is available
- Reflector: PMMA materials,shining silver reflector is the most popular, white/black reflectors are optional.
- Springs/Clips: Steel, high strength to fix onto the ceiling.
- Gland: stainess steel, waterproof
Control Gear / Led driver
- Driver brand: LiFud/Eagleries/Philips are optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Free flicker: Yes
- Power factor:>0.5 or >0.9
- Dimmable: No.
- THD:<15%
- Efficiency:>88%
- IP Rating: IP22
- Certificates: CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram available
- Color rendering index:>90
- Lumens:100lm-120lm/W output.
- SDCM:<5 or <3
- Lifetime:>50000Hrs
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
Emergency backup
Phase triac dimming, 0-10V dimming, DALI dimmable.
3CCT selectable
