Description
Parameters
Order model |
Wattage |
Length |
Width*Height |
Lumens |
Color temperature |
Ik rating |
IP Rate |
Installation |
Input voltage |
DATASHEET |
| LLS-TP-2F2K | 20W-24W | 2ft(600mm) | W110*H80mm | 100-140lm/w | 3000K,4000K,6500K | IK08 | IP65 | Suspended/Surface-mounted | 100/200-240VAC | Download |
| LLS-TP-4F2K | 40W-50W | 4ft(1200mm) | W110*H80mm | 100-140lm/w | 3000K,4000K,6500K | IK08 | IP65 | Suspended/Surface-mounted | 100/200-240VAC | Download |
| LLS-TP-5F2K | 60W | 5ft(1500mm) | W110*H80mm | 100-140lm/w | 3000K,4000K,6500K | IK08 | IP65 | Suspended/Surface-mounted | 100/200-240VAC | Download |
Specification
Materials & Finished
- Housing: materials as a standard, weatherproof, fireproof, flame retardant.
- Cover: Frosted PC Cover shade as standard, Good toughness, no yellowing, strong flame retardancy.
- Gland connector: M8-M10 waterproof gland.
- Clip: steel stainless clips are available.
- Surface-mounted part: Steel
Photometric Data
- Led driver brand: The LiFud driver is a standard, Osram driver is optional
- Input voltage: 220-240VAC 50/60Hz
- THD:<15%
- Power factor: 0.5 as standard, >0.9 is optional
- Efficiency:>88%
- IP Grade: IP20
- Certificates: CE CB ENEC TUV
- Warranty: 3/5 years
Optical
- Led chips: Bridgelux SMD
- Lumens:120-140lm/W
- Color temperature: 3000K warm white; 4000K daylight; 6000-6500k cold white
- LM80
- SDCM:<5%
