Description
Parameters
Image |
Order model |
Wattage |
Cut out |
Lumens |
Color temperature |
Beam angle |
Power Factor |
Input voltage |
DATASHEET |
 |
LLS-DL-7WF-R | 7W±5% | Φ105mm | 650-770lm | 3000K,4000K,6500K | 24/36° | >0.5 or 0.9 | 110V/220-240VAC 50/60Hz | Download |
|
LLS-DL-10WF-R | 10W±5% | Φ135mm | 900-1100lm | 3000K,4000K,6500K | 24/36° | >0.5 or 0.9 | 110V/220-240VAC 50/60Hz | Download |
 |
LLS-DL-7WF-S | 7W±5% | L105*W105mm | 630-770lm | 3000K,4000K,6500K | 24/36° | >0.5 or 0.9 | 110V/220-240VAC 50/60Hz | Download |
|
LLS-DL-10WF-S | 10W±5% | L135*W135mm | 900-1100mm | 3000K,4000K,6500K | 24/36° | >0.5 or 0.9 | 110V/220-240VAC 50/60Hz | Download |
Specification
Body & Finished
- Heat sink: die-cast aluminum body, black/white powder-coated.
- Frame: Plaster materials.
- Rimless hardware: metal with a hole, easy to fix by screws.
Control Gear/Led driver
- Control Gear brand: LiFud/Eagleries as standard, Osram/Philips drivers are optional.
- Input voltage: 220-240VAC 50/60Hz
- THD:<15%
- Power Factor: 0.5 as standard, >0.9 PF optional.
- Efficiency:>85%
- Certificates: CE TUV CB, ENEC
- Warranty: 3/5 years
Optical
- Led chips brand: Bridgelux /Osram / Citizen
- Lumens: 120-140lm/W
- CRI:>90
- Color temp: 3000K warm white, 4000-4500k cold white, 5700-6200k cold white
- LM80
- Lifetime: >100000hrs
Option
- Zigbee smart controller for Phone APP, Google Home, and AMAZON Alexa.
- Phase dimming /0-10V/DALI Dimmable
- Low voltage DC12V/DC24V/DC36V/DC48V/60V
- Emergency battery backup
FAQ
Q: Do you have frameless spotlights that are adjustable?
A: Yes, LUMIOS offers a wide range of trimless lights, including round/square frameless downlights and trimless spotlights.
