Description
Parameters
| Image | Order model | Wattage | Dimension | Cut out | Lumens | Color temperature | CRI | Input voltage | Datasheet |
 |
LLS-DL-10WG-08 | 10W±5% | Φ90*98mm | Φ70-75mm | 930-1100lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
|
LLS-DL-15WG-08 | 15W±5% | Ø109*107mm | Φ95mm | 1300-1600lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
|
LLS-DL-20WG-08 | 20W±5% | Ø109*107mm | Φ95mm | 1800-2100mm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
|
LLS-DL-30WG-08 | 30W±5% | Ø134*130mm | Φ110-120mm | 2800-3200lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
 |
LLS-DL-20WG-08-A | 20W±5% | Φ90*97mm | Φ75-80mm | 2000-2200lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
|
LLS-DL-30WG-08-A | 30W±5% | Φ110*115mm | Φ95-100mm | 2800-3300lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
|
LLS-DL-40WG-08-A | 40W±5% | Φ125*125mm | Φ115mm | 3800-4400lm | 3000K; 4000K; 6500K | >92 | 100/220-240VAC 50/60Hz | Download |
Specification
Body & Finished
- Housing: Die-cast aluminum body
- Lens/Diffuser: Polycarbonate lens. 15/24/36/50° design
- Clips: steel
- Trim: Aluminum
Control Gear & Led driver
- Led driver brand: LiFud/ Eagleries as standard, Osram, Philips driver can be optional
- Working voltage:100/220-265VAC 50/60Hz or 220-240VAC 50/60Hz.
- Power Factor:>0.5 as standard, 0.9 as an option
- Efficiency:>88%
- IP Rating: IP20
- Surge protection: 1-2KV
- Working temperature:-25℃/+50℃
- Compliance: CE RoHS CB CCC ENEC TUV SAA
- Warranty:3/5Years.
Optical
- Led chips: Bridgelux as a standard, Osram/Philips COB options
- CRI:>92
- Color temp: 3000K-3500K, 4000-4500K, 5000-5700K, 6000-6500K
- Lumens: 110-140LM/W
- LM80 reports
Option
- Dimming (Triac /0-10V/DALI Dimmable)
- Emergency battery backup (30% power with 1hours 2hours 3hours last)
Application
Downlight can be installed directly from the box into a wide range of ceiling types including thicknesses from 5mm-40mm. please refer to the hole size of the specific luminaire and make a round hole in the ceiling. Then use clips to fix it.
