Description
Parameters
Order model |
Wattage |
Dimension |
Cut out |
Lumens |
Color temperature |
IP Rate |
CRI(Ra) |
Input voltage |
Datasheet |
| LLS-DL-7WE | 7W±5% | Φ108*H50mm | Φ90mm | 700-800lm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-9WE | 9W±5% | Φ115*H50mm | Φ95mm | 810-1000lm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-12WE | 12W±5% | Φ145*H50mm | Φ125mm | 1100-1300mm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-15WE | 15W±5% | Ø180*H55mm | Φ165mm | 1450-1600lm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-18WE | 18W±5% | Ø180*H55mm | Φ165mm | 1850-2000lm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-24WE | 24W±5% | Ø190*H55mm | Φ175mm | 2250-2400lm | 3000K, 4000K,6500K | IP44 front | >80/90 | 110/220-240VAC 50/60Hz | Download |
Specification
Materials & Finished
- Heat sink: die-cast aluminum body, Matt white as a standard, black powder-coated can be optional.
- Cover: Polycarbonate PC Cover.
- Spring Clip: steel, strong
Control Gear/ Led driver
- Led driver brand: Guanx/LiFud/ Eagleries as standard; Osram/Philips/ Boke/ EUCHIPS/ SUNRICHER brand as optional.
- Input voltage: 110/220-240VAC 50/60Hz.
- Power Factor:>0.5 as standard, 0.9 optional
- Efficiency:>87%
- IP Grade: IP22
- THD:<15%
- Surge protection: 1-2KV
- Working temp: -25℃/+55℃
- Certificate: TUV CE RoHS ENEC CB
- Warranty: 3/5 years.
Optical
- Light source brand: Bridgelux/Osram SMD chips
- Chips lumens:110-130lm/W
- CRI: >80 as standard, >90 is optional
- UGR:<20
- Color temperature: 2700-3000K, 4000-4500K, 5700-6500K
- SDCM:<5
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80)
Option
- Emergency backup (2-5W with 1-3hours)
- Dimmable ( phasing dimmable, 0-10V and DALI dimmable optional)
Installation
