Description
Parameters
Order Model |
Wattages |
Dimension |
Cut out |
UGR |
Color temperature |
Beam angle |
IP rate |
CRI |
Input voltage |
Datasheet |
| LLS-DL-7WA-04 | 7W±5% | Ø85*H46 | Ø70mm | <17 | 3000k-6000K | 90° | IP44 | >80 or >90 | 100/220-240VAC | Download |
| LLS-DL-15WA-04 | 15W±5% | Ø138*H64 | Ø120mm | <17 | 3000k-6000K | 90° | IP44 | >80 or >90 | 100/220-240VAC | Download |
| LLS-DL-20WA-04 | 20W±5% | Ø185*H79 | Ø165mm | <17 | 3000k-6000K | 90° | IP44 | >80 or >90 | 100/220-240VAC | Download |
| LLS-DL-25WA-04 | 25W±5% | Ø185*H79 | Ø165mm | <17 | 3000k-6000K | 90° | IP44 | >80 or >90 | 100/220-240VAC | Download |
Specification
Materials & Finished
- Body: aluminum body, matt white
- Trim: Aluminum, white finished, deep design with anti-glare performance
- Springs/Clips: Steel, high strength to fix onto the ceiling.
Control Gear / Led driver
- Driver brand: Eagleries as standard; LiFud/Euchips/Osram/Philips/Letch/Sunricher optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Power factor:>0.9
- THD:<10%
- Efficiency:>87%
- IP Rating: IP22
- Certificates: TUV CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram available
- Color rendering index:>80
- Lumens:100lm-120lm/W output.
- SDCM:<3
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
Option
- 0-10V dimmable, Dali dimmable downlight
- Emergency with battery kits
- 3CCT Tunable white
