Description
Parameters
Product Code |
Wattage |
Dimension |
Lumens |
Color temperature |
Beam angle (deg) |
IP Rating |
CRI |
Input voltage |
Datasheet |
| LLS-PL12010 | 18W-24W±5% | 1195*95mm | 1800-2400lm | 2700-6500K | 110° | IP22/IP44 | >80 | 110/220-240VAC 50/60Hz | Download |
| LLS-PL12015 | 24W-30W | 1195*145mm | 2400-3000lm | 2700-6500K | 110° | IP22/IP44 | >80 | 110/220-240VAC 50/60Hz | Download |
| LLS-PL12020 | 30W -36W | 1195*195mm | 3000-3600lm | 2700-6500K | 110° | IP22/IP44 | >80 | 110/220-240VAC 50/60Hz | Download |
| LLS-PL120100 | 100W -140W | 1195*995mm | 11000-12000lm | 2700-6500K | 110° | IP22/IP44 | >80 | 110/220-240VAC 50/60Hz | Download |
| LLS-PL120120 | 100W -160W | 1195*1195mm | 14000-16000lm | 2700-6500K | 110° | IP22/IP44 | >80 | 110/220-240VAC 50/60Hz | Download |
Specification
Materials & Finished
- Back-lit design without LGP, avoiding any yellowing change.
- PCB with lens, Uniform luminescence, luminous efficiency as high as 100lm/w.
- Aluminum frame, white/silver/Black available.
- High-quality transformer included, free flicker, better lighting performance.
Control Gear / Led driver
- Driver brand: Eagleries as standard; LiFud/Euchips/Osram/Philips optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Power factor:>0.5 or 0.9
- THD:<15%
- Efficiency:>87%
- IP Rating: IP22
- Certificates: CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram/Citizen available
- Color rendering index:>80
- Lumens:100lm-150lm/W output.
- SDCM:<5 or <3
- Lifetime:>50000Hrs
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
Options
- TRIAC/0-10V/DALI dimmable
- Emergency backup (5W/7W with 1hrs 2hrs or 3Hours duration)
- Surface mounted frame and suspended ropes.
Install & Wiring
There are many different installation methods for your choice. Hanging, Embedded, Surface mounted. Just download the installation guide, please.
Application & Project Case
metro stations, offices, education and commercial spaces
