Description
Parameters
Order Model |
Wattages |
Dimension |
Cut out |
Lumens |
Beam angle |
Color temperature |
CRI |
IP Rating |
Input voltage |
Datasheet |
| LLS-DL-30WS | 30W±5% | Ø160*H85mm | Φ140-145mm | 2700-3200lm | 15/24/36/50° | 3000K,4000K,6000K | >92 | IP44 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-35WS | 35W±5% | Ø185*H95mm | Φ160-170mm | 3300-3600lm | 15/24/36/50° | 3000K,4000K,6000K | >92 | IP44 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-40WS | 40W±5% | Ø185*H95mm | Φ160-170mm | 3800-4400lm | 15/24/36/50° | 3000K,4000K,6000K | >92 | IP44 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-50WS | 50W±5% | Ø215*H110mm | Φ190-200mm | 4800-5300lm | 15/24/36/50° | 3000K,4000K,6000K | >92 | IP44 | 110/220-240VAC 50/60Hz | Download |
Specification
Materials & Finished
- Housing: aluminum, matt white as standard, matt black is available
- Reflector: PMMA materials, white/black reflectors as standard, bright silver/ bright black reflectors optional.
- Springs/Clips: Steel, high strength to fix onto the ceiling.
Control Gear / Led driver
- Driver brand: Eagleries as standard; LiFud/Euchips/Osram/Philips/Letch/Sunricher optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Free flicker: Yes
- Power factor:>0.5 or >0.9
- Dimmable: No.
- THD:<15%
- Efficiency:>88%
- IP Rating: IP22
- Certificates: TUV CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram available
- Color rendering index:>90
- Lumens:100lm-120lm/W output.
- SDCM:<3
- Lifetime:>50000Hrs
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
Options
Emergency backup
Phase triac dimming, 0-10V dimming, DALI dimmable.
with Zigbee driver to be a smart downlight fixture.
