Description
Order Model |
Wattage |
Dimension |
Cut out |
Lumens |
Color temperature |
Beam angle |
Glare Value |
CRI |
Input voltage |
Datasheet |
| LLS-DL-5WG-0 | 5W±5% | Ø65*H51mm | Ø55mm | 500lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-7WG-0 | 7W±5% | Ø75*H59mm | Ø65mm | 700lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-10WG-0 | 10W±5% | Ø85*H59mm | Ø75mm | 1000lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-12WG-0 | 12W ±5% | Ø90*H75mm | ø 75mm | 1000-1300lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-14WG-0 | 14W±5% | Ø90*H75mm | ø 75mm | 1400-1500lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-18WG-0 | 18W ±5% | Ø90*H105mm | ø 75mm | 1800-1900lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
| LLS-DL-20WG-0 | 20W ±5% | Ø90*H105mm | ø 75mm | 2000-2200lm | 2700-6500K or 3CCT | 24/36° | <7 | >90 | 110/220-240VAC 50/60Hz | Download |
Materials & Finished
- Trim frame: aluminum body, matt white/black.
- Lens: PMMA materials, black finish
- Springs/Clips: Steel, high strength to fix onto the ceiling.
- Heat sink: Aluminum, black color finished
Control Gear / Led driver
- Driver brand: Eagleries/LiFud/Guanx/Osram/Philips are optional.
- Input voltage: 110/220-240VAC 50/60Hz
- Output Voltage: 36VDC
- Power factor:>0.5 or 0.9
- Free flicker: Yes
- THD:<15%
- Efficiency:>87%
- IP Rating: IP44
- Certificates: BIS CE RoHS ENEC CB
- Warranty: 3/5Years
Optical
- Light source brand: Bridgelux as standard, Osram/Citizen available
- Color rendering index:>90 (97max)
- Lumens:100lm-120lm/W output.
- SDCM:<5 or <3
- Beam angle: 24/36°.
- Lifetime:>50000Hrs
- Low glare value: UGR<10
- Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
- Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
- Emergency battery packs. ( emergency kits for 1-3Hours for 2-5Watt)
- Zigbee smarting downlight
- Triac phase dimmable/ 0-10V dimmable/ DALI dimmable
Quick tool-free installation design, the downlighter has a strong fixing bracket, which can be quickly installed on a 1-40mm thick ceiling. Check the installation drawing here, please.
- Commercial lighting: Hotels, offices, shopping malls, schools, hospitals, supermarkets.
- Residential lighting: Living room, bedroom, kitchen room, etc..
