Description
Parameters
Product Code |
Wattage |
Dimension |
Lumens |
CRI(Ra) |
Power factor |
UGR |
Color Temperature |
Input voltage |
Datasheet |
| LLS-PL6060-40WH | 40W±5% | 595*595*25mm | 3800-4100lm | >80 | >0.9 | <19 | 3000K4000K6500K | 110/220-240VAC 50/60Hz | Download |
| LLS-PL6060-48WH-A | 48W±5% | 595*595*25mm | 4800-5200lm | >80 | >0.9 | <19 | 3000K4000K6500K | 110/220-240VAC 50/60Hz | Download |
| LLS-PL6060-60WH-A | 60W±5% | 595*595*25mm | 6000-6600lm | >80 | >90 | <19 | 3000K4000K6500K | 110/220-240VAC 50/60Hz | Download |
Specification
Materials & Finished
- A heat sink (Housing): Metal bottom, 2.5mm thickness-3mm thickness, Matt white as standard, Matt black optional.
- Diffuser/cover: Polystyrene PS Cover.
- Lens: High temperature resistant optical lens, uniform light emission
Control Gear / Led driver
- Brand: LiFud/Eagleries/OSRAM/PHILIPS
- Input voltage:220-265VAC 50/60Hz
- Power Factor:>0.9
- Efficiency:>88%
- Surge protection:1-2KV
- Type: ON/OFF
- Working life:>50000Hrs
- IP Rate: IP20
- Certificates: CE ENEC TUV CB
- Warranty: 2/3/5years
Optical
- LED Chips: SMD2835
- Color rendering index:>80
- Lumens:100lm/W
- SDCM:<5
- Color temperature: 3000K/4000K/6500K
Options
- TRIAC/0-10V/DALI dimmable
- Emergency backup (30% power with 1hrs 2hrs or 3Hours duration)
- Surface mounted type
Install & Wiring
- Recessed installation is A standard version, just put it onto the grid ceiling, easy installation.
- Suspension installation is available, but the steel ropes for hanging need to be ordered additionally.
Application & Project Case
Commercial lighting projects, including offices, meeting rooms, supermarkets, schools, and hospitals
